3M Tape 92

Name: 3M Tape 92
Brand: Samco Technologies
Price: 250 INR
Availability: InStock

Price 250 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

3M Tape 92 Specification

Elongation
10%

Shelf Life
5 Years from the date of manufacture

Length
33 m

Peeling Strength
19 N/25mm

Thickness
2.7 mils (0.07 mm)

Adhesive Side
Single Sided

Tape Type
Polyimide Tape

Material
Polyimide Film

Adhesive Type
Silicone Adhesive

Color
Amber

Tape Length
33 m

Tape Thickness
0.07 mm

Use
High-Temperature Insulating

Tape Width
12 mm

Temperature Resistance
Up to 260°C

Flame Retardant
Yes, UL Listed

RoHS Compliant
Yes

Adhesion to Steel
30 oz/in (3.3 N/cm)

Dielectric Strength
6500V

Core Diameter
76 mm (3 inches)

Application
Wave solder masking, coil insulation, printed circuit board insulation

Backing Thickness
0.05 mm

3M Tape 92 Trade Information

Minimum Order Quantity
10 Pieces

Main Domestic Market
All India

About 3M Tape 92

3M Polyimide Film Electrical Tape 92 is an amber UL recognized flame retardant, 2.75-mil (0.070 mm) thick tape composed of a 1-mil (0.025 mm) thick polyimide film backing coated on one side with a non-corrosive, thermosetting silicone pressure-sensitive adhesive. i Commonly used in wrapping coils, capacitors, wire harnesses, transformers and anchoring leads i Commonly used in printed circuit board assembly as a solder masking tape i Adhesive requires no heat, moisture or other manner of preparation to affect application i Designed for continuous operation not exceeding 180C (356F) per UL listing

High-Temperature Protection

3M Tape 92 is designed to perform in extreme high-temperature conditions, making it suitable for wave solder masking, coil insulating, and other demanding electronic applications. It can resist heat up to 260C while maintaining its adhesive and physical properties, ensuring reliable performance during manufacturing processes.

Reliable Electrical Insulation

With a dielectric strength of 6500V and backing thickness of 0.05 mm, this tape provides efficient electrical insulation. It meets strict industry standards, including RoHS compliance and UL listing, which ensures dependable safety in circuit board and component insulation.

Durability and Ease of Use

The polyimide backing offers excellent mechanical strength, elongation of 10%, and robust adhesion to steel (3.3 N/cm). Its single-sided silicone adhesive ensures easy application and removal from surfaces without residue, making it ideal for temporary masking and long-term insulation.

FAQ's of 3M Tape 92:

Q: How should 3M Tape 92 be applied for optimum performance?

A: To achieve the best results, ensure the surface is clean and dry before application. Firmly press the tape onto the intended area, whether for coil insulation, wave solder masking, or PCB protection, to guarantee secure adhesion and effective insulation.

Q: What are the main benefits of using 3M Tape 92 in electronic manufacturing?

A: 3M Tape 92 offers high-temperature resistance up to 260C, strong electrical insulation, and flame retardancy. It protects delicate components during soldering and manufacturing, provides RoHS compliance, and is UL listed for added safety assurance.

Q: When is it recommended to use 3M Tape 92 instead of other tapes?

A: 3M Tape 92 should be chosen when applications demand high thermal resistance, electrical insulation, and flame retardancy, such as wave solder masking, coil wrapping, and PCB insulation in electronics manufacturing environments.

Q: Where can 3M Tape 92 be sourced in India?

A: 3M Tape 92 can be sourced from authorized suppliers and traders across India. Many distributors offer nationwide delivery, ensuring you receive genuine and compliant products suitable for industrial and electronic applications.

Q: What is the process for removing 3M Tape 92 after high-temperature exposure?

A: Once the tape has cooled down after exposure to high temperatures, gently peel it off the surface. The silicone adhesive is designed to remove cleanly without leaving residue, making post-process cleanup quick and efficient.

Q: Is 3M Tape 92 safe and compliant with international standards?

A: Yes, 3M Tape 92 is both UL listed and RoHS compliant, indicating it meets rigorous international safety, environmental, and quality standards, which is essential in critical electronic and industrial usage.
